Weidmuller ZDK 2.5/1.5 Double-Level Feed-Through Terminal Block, Tension Clamp, 2.5mm², 500V, 20A, Beige
PART NO:
1674300000 /
SKU:
1023230
$9.64
inc. GST
$8.76
ex. GST
Product Specification
Brand:
Weidmuller
Type:
Feed Through Terminal
Width:
5.10 mm
Colour:
Beige
Function:
Double Level Feed Through
Material:
Wemid
Blade Size:
0.60 x 3.50 mm
Cable Size:
24 to 14 AWG
Model/Series:
Z
Mounting Type:
TS35 Rail Mount
Rated Current:
20 A
Rated Voltage:
500 V AC/DC
Certifications:
CCC;CE;CSA;DNV;IECEx;KEMA;KEUR;UR E60693;RoHS;UL;KC KOSHAEX;UKCA;ATEX;UKCA-EX
Connection Type:
Tension Clamp
Number of Levels:
2
Stripping Length:
10 mm
Max Clamping Range:
2.50 mm²
Min Clamping Range:
0.05 mm²
Wire Cross Section:
2.50 mm²
Connection Direction:
Right
Number of Connections:
4
Max Operating Temperature:
+120 °C
Min Operating Temperature:
-50 °C
Depth:
53 mm
Height:
79.50 mm
Weight:
9.61 g
Model Part Code:
ZDK 2.5
