Weidmuller WDK 2.5 Double-Level Feed-Through Terminal Block, 2.5mm², 400V, 24A, Screw Connection, Beige, TS 35

PART NO: 1021500000 / SKU: 1012095
Weidmuller WDK 2.5 Double-Level Feed-Through Terminal Block, 2.5mm², 400V, 24A, Screw Connection, Beige, TS 35
$9.44
inc. GST
$8.58
ex. GST
Free shipping on orders over $100

Product Specification

Brand:
Weidmuller
Type:
Feed Through Terminal
Width:
5.10 mm
Colour:
Beige
Function:
Double Level Feed Through
Material:
Wemid
Blade Size:
0.60 x 3.50 mm
Cable Size:
30 to 12 AWG
Model/Series:
W
Mounting Type:
TS35 Rail Mount
Rated Current:
400 A
Rated Voltage:
400 V AC/DC
Certifications:
CCC;CE;CSA;cURusEX;IECEx;KEMA;KEUR;Lloyds Register;ATEX;UKCA-EX;UR E60693;RoHS;UL;NEMKO
Connection Type:
Screw
Number of Levels:
2
Stripping Length:
10 mm
Max Clamping Range:
4 mm²
Min Clamping Range:
0.05 mm²
Wire Cross Section:
2.50 mm²
Connection Direction:
Right
Number of Connections:
4
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
63 mm
Height:
69.50 mm
Weight:
3.62 g
Model Part Code:
WDK 2.5

Product Downloads

Datasheet
