Weidmuller WDU 50N Feed-Through Terminal Block, 50mm², 150A, 1000V, Screw Connection, Beige, TS 35
PART NO:
1820840000 /
SKU:
1023805
$43.91
inc. GST
$39.92
ex. GST
Product Specification
Brand:
Weidmuller
Type:
Feed Through Terminal
Width:
18.50 mm
Colour:
Beige
Function:
Single Level Feed Through
Material:
Wemid
Blade Size:
S4
Cable Size:
8 to 0 AWG
Model/Series:
W
Mounting Type:
TS35 Rail Mount
Rated Current:
150 A
Rated Voltage:
1000 V AC/DC
Certifications:
CCC;CE;CSA;cURusEX;IECEx;KEMA;KEUR;ATEX;UKCA-EX;UR E60693;RoHS;UL;INMETRO;UKCA
Connection Type:
Screw
Number of Levels:
1
Stripping Length:
24 mm
Max Clamping Range:
70 mm²
Min Clamping Range:
10 mm²
Wire Cross Section:
50 mm²
Connection Direction:
Closed
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
69.60 mm
Height:
70 mm
Weight:
84.38 g
Model Part Code:
WDU 50N
Product Downloads
