Weidmuller WSI 6/LD Fuse Terminal Block, 6mm², 10-36V AC/DC, 6.3A, Screw Connection, LED Indicator, Beige
PART NO:
1011300000 /
SKU:
1017092
$36.00
inc. GST
$32.73
ex. GST
Product Specification
Brand:
Weidmuller
Type:
Fuse Terminal
Width:
7.90 mm
Colour:
Beige
Function:
Single Level Feed Through
Material:
Wemid
Fuse Type:
G-Si. 5 x 20
Blade Size:
0.80 x 4.00 mm
Cable Size:
20 to 8 AWG
Model/Series:
W
Mounting Type:
TS35 Rail Mount
Rated Current:
6.30 A
Rated Voltage:
10 to 36 V AC/DC
Certifications:
CE;CSA;DNA;Lloyds Register;NEMKO;UKCA;UL;UR E60693;RoHS
Connection Type:
Screw
Number of Levels:
1
Stripping Length:
12 mm
Max Clamping Range:
10 mm²
Min Clamping Range:
0.50 mm²
Wire Cross Section:
6 mm²
Connection Direction:
On Side
Number of Connections:
2
Max Operating Temperature:
+120 °C
Min Operating Temperature:
-50 °C
Depth:
71.50 mm
Height:
60 mm
Weight:
19.47 g
Model Part Code:
WSI 6/LD 10-36V DC/AC
