Weidmuller WPE 6 Earth Terminal Block, 6mm², 800V, Screw Connection, Green/Yellow, TS35
PART NO:
1010200000 /
SKU:
1012074
$11.63
inc. GST
$10.57
ex. GST
Product Specification
Brand:
Weidmuller
Type:
Earth Terminal
Width:
7.90 mm
Colour:
Green;Yellow
Function:
Single Level Feed Through
Material:
Wemid
Blade Size:
4.00 x 0.80 mm
Cable Size:
20 to 8 AWG
Model/Series:
W
Mounting Type:
TS35 Rail Mount
Rated Voltage:
800 V DC
Certifications:
CCC;CE;CSA;CSAEX;cURusEX;DNV;IECEx;Ex I:KEMA;KEUR;ATEX;INMETRO;KC KOSHAEX;Lloyds Register;NEMKO;UKCA-EX;UL;UR E60693;RoHS
Connection Type:
Screw
Number of Levels:
1
Stripping Length:
12 mm
Max Clamping Range:
10 mm²
Min Clamping Range:
0.08 mm²
Wire Cross Section:
6 mm²
Connection Direction:
On Side
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
46.50 mm
Height:
56 mm
Weight:
25.98 g
Model Part Code:
WPE 6
