Weidmuller WFF 185 Feed-Through Terminal Block, 185mm², 1000V, 353A, Bolt/Screw Connection, Beige
PART NO:
1028600000 /
SKU:
1012101
$91.18
inc. GST
$82.89
ex. GST
Product Specification
Brand:
Weidmuller
Type:
Feed Through Terminal
Width:
55 mm
Colour:
Beige
Function:
Single Level Feed Through
Material:
Wemid
Stud Size:
M12
Stud Type:
Double
Cable Size:
8 AWG to 500 kcmil
Model/Series:
WFF
Mounting Type:
TS35 Rail Mount
Rated Current:
353 A
Rated Voltage:
1000 V AC;1500 V DC
Certifications:
CCC;CE;CSA;CSAEX;cURusEX;DNV;KEMA;KEUR;UR E60693;RoHS;UL;NEMKO;UKCA
Connection Type:
Threaded Stud
Number of Levels:
1
Tightening Torque:
14 to 31 Nm
Max Clamping Range:
240 mm²
Min Clamping Range:
10 mm²
Wire Cross Section:
185 mm²
Number of Connections:
2
Max Operating Temperature:
+120 °C
Min Operating Temperature:
-50 °C
Depth:
77.50 mm
Height:
163 mm
Weight:
411.20 g
Model Part Code:
WFF 185
Product Downloads
