Product Specification
Brand:
Weidmuller
Type:
Feed Through Terminal
Depth:
46.5 mm
Width:
5.1 mm
Colour:
Orange
Height:
60 mm
Weight:
7.49 g
Function:
Single Level Feed Through
Material:
Wemid
Cable Size:
30 to 12 AWG
Model/Series:
WDU
Mounting Type:
TS35 Rail Mount
Rated Current:
24 A
Rated Voltage:
800 V
Certifications:
ATEX;CCC;CE;CSA;CSAEX;cURusEX E184763;DNV;IECEx;INMETRO;KC KOSHAEX;KEMA KEUR;LR;RoHS;UKCA;UL;UR E60693
Connection Type:
Screw
Ecom Hide Price:
No
Model Part Code:
WDU 2.5 OR
Number of Levels:
1
Stripping Length:
10 mm
Max Clamping Range:
4 mm²
Min Clamping Range:
0.05 mm²
Wire Cross Section:
4 mm²
Connection Direction:
On Side
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
