The UR20-FBC-PB-DP-V2 (order no. 2614380000) is a u-remote fieldbus coupler for PROFIBUS DP-V1, connecting via a 9-pole SUB-D socket and a Micro USB 2.0 configuration interface, with galvanic isolation between the field bus and system bus. It offers a fieldbus transmission rate of up to 12 Mbit/s and a system bus speed of up to 48 Mbit/s, addressing up to 64 modules, with 488 bytes of process data and 244 bytes each of parameter and diagnostic data. It feeds up to 10 A into both the input and output current paths (4 A max. for the system), measures 76 x 120 x 52 mm, and weighs 247 g, with a stated humidity range of 10-90% (non-condensing). The matching end brackets are included with the coupler.

Weidmüller's u-remote is a remote I/O concept with IP20 protection focused on tailored planning, faster installation and safer start-up. Its narrowest-on-the-market modular design and tool-free assembly reduce the need for cabinet space and power-feed modules, while the modular sandwich design and integrated web server speed up installation in the cabinet and on the machine. Status LEDs on each channel and module support reliable diagnosis and rapid service. It is RoHS conformant and holds cULus (E141197) and cULusEX (E223527) certification.
