Weidmuller IE-SW-EL05-5TX Unmanaged Ethernet Switch, 5-Port 10/100BaseTX, DIN Rail Mount

PART NO: 2682130000 / SKU: 1034890
Weidmuller IE-SW-EL05-5TX Unmanaged Ethernet Switch, 5-Port 10/100BaseTX, DIN Rail Mount
$145.20
inc. GST
$132.00
ex. GST
Free shipping on orders over $100
  • Engineered for durability in demanding industrial environments
  • Wide temperature tolerance from -40°C up to 75°C
  • Compact design with convenient DIN rail mounting for easy installation
  • Designed for efficiency with minimal power usage

Product Specification

Brand:
Weidmuller
Type:
Unmanaged Network Switch
Width:
26.10 mm
Humidity:
5 to 95 %
IP Rating:
IP30
Mounting Type:
DIN Rail Mount
Rated Current:
100 mA
Rated Voltage:
10.80 to 52.80 V DC;18 to 36 V AC
Certifications:
CE;cULus;UKCA;KC;RoHS
Connection Type:
RJ-45
Number of Ports:
5
Housing Material:
Metal
Transmission Speed:
10/100 Mbps
Max Operating Temperature:
+75 °C
Min Operating Temperature:
-40 °C
Depth:
70 mm
Height:
95 mm
Weight:
205 g
Model Part Code:
IE-SW-EL05-5TX

Warranty Information

5 Years

Product Downloads

Datasheet
