Weidmuller AKZ 4 Feed-Through Terminal Block, 4mm², 400V, 32A, Screw Connection, Beige, DIN Rail TS 15
PART NO:
0294360000 /
SKU:
1011938
$3.11
inc. GST
$2.83
ex. GST
Product Specification
Brand:
Weidmuller
Type:
Feed Through Terminal
Width:
6.1 mm
Colour:
Beige
Function:
Single Level Feed Through
Material:
Wemid
Blade Size:
0.6 mm x 3.5 mm
Cable Size:
24 to 12 AWG
Model/Series:
SAK
Mounting Type:
TS15 Rail Mount
Rated Current:
32 A
Rated Voltage:
400 V AC/DC
Certifications:
CCC;CE;CSA;IECEx;INMETRO;KEMA;KEUR;ATEX;UKCA-EX;UR E60693;RoHs;UKCA;UL
Connection Type:
Screw
Number of Levels:
1
Stripping Length:
8 mm
Max Clamping Range:
6 mm²
Min Clamping Range:
0.13 mm²
Wire Cross Section:
4 mm²
Connection Direction:
Right
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
29 mm
Height:
30.5 mm
Weight:
4.55 g
Model Part Code:
AKZ 4
Product Downloads
