Weidmuller A2C 10 Feed-Through Terminal Block, 10mm², 57A, 1000V, Push-In, 2 Connections, Beige, TS 35 Mount
PART NO:
2490360000 /
SKU:
1030803
$5.09
inc. GST
$4.63
ex. GST
Product Specification
Brand:
Weidmuller
Type:
Feed Through Terminal
Width:
10 mm
Colour:
Beige
Function:
Single Level Feed Through
Material:
Wemid
Blade Size:
1.0 x 5.5 mm
Cable Size:
20 to 6 AWG
Model/Series:
A2C
Mounting Type:
TS35 Rail Mount
Rated Current:
57 A
Rated Voltage:
1000 V
Certifications:
CCCEX;CE;CSA;cURus;cURus Ex;DNV;KEMA;KEUR;KOSHA Ex;UKCA;RoHS
Connection Type:
Push In
Number of Levels:
1
Stripping Length:
18 mm
Max Clamping Range:
16 mm²
Min Clamping Range:
0.5 mm²
Wire Cross Section:
10 mm²
Connection Direction:
Right
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
51.5 mm
Height:
80.5 mm
Weight:
32.315 g
Model Part Code:
A2C 10
