Weidmuller A2C 1.5 BL Feed-Through Terminal Block, 1.5mm², 17.5A, 500V, Push-In, 2 Connections, Blue, TS 35
PART NO:
1552820000 /
SKU:
1030242
$2.05
inc. GST
$1.86
ex. GST
Product Specification
Brand:
Weidmuller
Type:
Feed Through Terminal
Width:
3.5 mm
Colour:
Blue
Function:
Single Level Feed Through
Material:
Wemid
Blade Size:
0.4 x 2.0 mm
Cable Size:
26 to 14 AWG
Model/Series:
A2C
Mounting Type:
TS35 Rail Mount
Rated Current:
17.5 A
Rated Voltage:
500 V
Certifications:
CCCEX;CE;CSA;cURus;cURus Ex;DNV;Ex I;IEC Ex;KEMA;KEUR;KOSHA Ex;UKCA;RoHS
Connection Type:
Push In
Number of Levels:
1
Stripping Length:
8 mm
Max Clamping Range:
1.5 mm²
Min Clamping Range:
0.14 mm²
Wire Cross Section:
1.5 mm²
Connection Direction:
Right
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
33.5 mm
Height:
55 mm
Weight:
4.04 g
Model Part Code:
A2C 1.5 BL
