Weidmuller WTTB 6 Measuring Transformer Disconnect Terminal Block, 6mm², 30A, 500V
PART NO:
2710090000 /
SKU:
1035417
$12.35
inc. GST
$11.23
ex. GST
Product Specification
Brand:
Weidmuller
Type:
Disconnect Terminal
Depth:
69 mm
Width:
8.1 mm
Colour:
Dark Beige
Height:
100 mm
Weight:
32.173 g
Function:
Termination
Material:
Wemid
Blade Size:
0.8 x 4.0 mm
Cable Size:
22 to 8 AWG
Model/Series:
WTTB
Mounting Type:
TS32 Rail Mount;TS35 Rail Mount
Rated Current:
30 A
Rated Voltage:
500 V
Certifications:
CE;CSA;cURus E60693;DNV;KEMA KEUR;RoHS;UKCA;UL
Connection Type:
Screw
Ecom Hide Price:
No
Model Part Code:
WTTB 6
Cross Disconnect:
No
Number of Levels:
1
Stripping Length:
12 mm
Max Clamping Range:
10 mm²
Min Clamping Range:
0.5 mm²
Wire Cross Section:
10 mm²
Connection Direction:
On Side
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Product Downloads
