Product Specification
Brand:
Weidmuller
Type:
Fuse Terminal
Depth:
75 mm
Width:
6.1 mm
Colour:
Dark Beige
Height:
60 mm
Weight:
18.12 g
Function:
Termination
Material:
Wemid
Fuse Type:
G-Si. 5 x 20
Blade Size:
0.6 x 3.5 mm
Cable Size:
24 to 10 AWG
Model/Series:
W2C
Mounting Type:
TS35 Rail Mount
Rated Current:
6.3 A
Rated Voltage:
500 V
Certifications:
ATEX;CE;CSA;cURus E60693;cURusEX E184763;DNV;IECEx;KEMA KEUR;RoHS;UKCA;UL
Connection Type:
Screw
Ecom Hide Price:
No
Model Part Code:
W2C 4 FS DB
Number of Levels:
1
Stripping Length:
8 mm
Max Clamping Range:
6 mm²
Min Clamping Range:
0.25 mm²
Wire Cross Section:
6 mm²
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
