Weidmuller SAKC 10 2STB Test-Disconnect Terminal Block, 10mm², 500V, 26A, Screw Connection, TS 32 DIN Rail
PART NO:
0324120000 /
SKU:
1029757
$22.43
inc. GST
$20.39
ex. GST
Product Specification
Brand:
Weidmuller
Type:
Disconnect Terminal
Width:
12 mm
Colour:
Medium Yellow
Function:
Single Level Feed Through
Material:
KrG
Blade Size:
1.00 x 5.50 mm
Cable Size:
22 to 8 AWG
Model/Series:
SAK
Mounting Type:
TS32 Rail Mount
Rated Current:
26 A
Rated Voltage:
500 V AC/DC
Certifications:
CE;CSA;UKCA;UR E60693;RoHS
Connection Type:
Screw
Cross Disconnect:
No
Number of Levels:
1
Stripping Length:
12 mm
Max Clamping Range:
10 mm²
Min Clamping Range:
0.33 mm²
Wire Cross Section:
10 mm²
Connection Direction:
On Side
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
52.50 mm
Height:
65 mm
Weight:
46.20 g
Model Part Code:
SAKC 10 2STB
