Weidmuller RCM Relay Module, 4PDT, 6A, 24V DC Coil, Test Button, LED Indicator, DIN Rail Mount

PART NO: 8921030000 / SKU: 1024183
Weidmuller RCM Relay Module, 4PDT, 6A, 24V DC Coil, Test Button, LED Indicator, DIN Rail Mount
$36.50
inc. GST
$33.18
ex. GST
Free shipping on orders over $100

Product Specification

Brand:
Weidmuller
Type:
Power Relay
Width:
27.20 mm
Colour:
Black
Length:
78.30 mm
IP Rating:
IP20
Test Button:
Yes
Coil Voltage:
24 V DC
Model/Series:
Rider
Mounting Type:
TS35 Rail Mount
Rated Current:
6 A
Rated Voltage:
240 V AC
Terminal Type:
Screw
Certifications:
CSA;DNV;cURus;RoHS;UKCA
Connection Type:
Screw
Control Voltage:
24 V DC
Mechanical Life:
20M Cycles
Contact Material:
AgNi
Status Indicator:
Yes
Number of Contacts:
4
Contact Configuration:
4CO
Protective Circuit Type:
Diode
Rated Switching Current:
6 A
Rated Switching Voltage:
240 V AC
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-40 °C
Height:
77 mm
Weight:
99.90 g
Model Part Code:
RCMKIT-I 24VDC 4CO LD

Product Downloads

Datasheet
