Weidmuller AIO 2.1 Insertion Bridge for Terminal Blocks, 1.5mm², 13.5A

PART NO: 1992260000 / SKU: 1029972
Weidmuller AIO 2.1 Insertion Bridge for Terminal Blocks, 1.5mm², 13.5A
$6.06
inc. GST
$5.51
ex. GST
Free shipping on orders over $100

Product Specification

Brand:
Weidmuller
Type:
Initiator/Actuator Terminal
Depth:
42 mm
Width:
3.5 mm
Colour:
Dark Beige
Height:
80 mm
Weight:
6.54 g
Function:
Termination
Material:
Wemid
Fuse Type:
G-Si. 5 x 20
Blade Size:
0.4 x 2.0 mm
Cable Size:
26 to 14 AWG
Model/Series:
AIO
Mounting Type:
TS35 Rail Mount
Rated Current:
13.5 A
Rated Voltage:
250 V
Certifications:
ATEX;Bureau Veritas (BV);CCC;CE;CSA;cURus E60693;DNV;IECEx;KEMA KEUR;RoHS;UKCA;UL
Connection Type:
Push In
Ecom Hide Price:
No
Model Part Code:
AIO21 1.5 SI
Number of Levels:
2
Stripping Length:
8 mm
Max Clamping Range:
1.5 mm²
Min Clamping Range:
0.14 mm²
Wire Cross Section:
1.5 mm²
Connection Direction:
Top
Number of Connections:
4
Push In Mechanism Type:
Spring-Loaded
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C

Product Downloads

Datasheet Certificate 1 Certificate 2 Certificate 3 Certificate 4 Certificate 5
