Weidmuller ADT 2.5 2C Test-Disconnect Terminal Block, 2.5mm², 20A, 500V, Push-In, 2 Connections, Beige, TS 35

PART NO: 1989800000 / SKU: 1027560
Weidmuller ADT 2.5 2C Test-Disconnect Terminal Block, 2.5mm², 20A, 500V, Push-In, 2 Connections, Beige, TS 35
$7.87
inc. GST
$7.15
ex. GST
Free shipping on orders over $100

Product Specification

Brand:
Weidmuller
Type:
Test Disconnect Terminal
Width:
5.1 mm
Colour:
Beige
Function:
Single Level Feed Through
Material:
Wemid
Blade Size:
0.6 x 3.5 mm
Cable Size:
28 to 12 AWG
Model/Series:
ADT
Mounting Type:
TS35 Rail Mount
Rated Current:
20 A
Rated Voltage:
500 V
Certifications:
CCCEX;CE;CSA;cURus;DNV;IEC Ex;KEMA;KEUR;KOSHA Ex;UKCA;RoHS
Connection Type:
Push In
Cross Disconnect:
No
Number of Levels:
1
Stripping Length:
10 mm
Max Clamping Range:
4 mm²
Min Clamping Range:
0.14 mm²
Wire Cross Section:
2.5 mm²
Connection Direction:
Top
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
37.65 mm
Height:
77.5 mm
Weight:
9.579 g
Model Part Code:
ADT 2.5 2C

Product Downloads

Datasheet
