Bernstein AG SLK Solenoid Plastic Body Safety Interlock Switch, 4NC, 24V AC/DC, IP67
PART NO:
6018169054 /
SKU:
1037671
$441.40
inc. GST
$401.27
ex. GST
Product Specification
Brand:
Bernstein
Type:
Interlock Safety Switch
Class:
Class II
Width:
45 mm
Length:
42.50 mm
IP Rating:
IP67
Tolerance:
±15 %
Model/Series:
SLK
Actuator Type:
Interlock
Rated Voltage:
24 V AC/DC
Certifications:
GS ET 19;EN 60 204-1;EN 60 947-1;EN 60 947-5-1;EN 1088;EN ISO 12100-1;EN ISO 12100-2
Operation Type:
Spring Force & Magnetic Locking
Connection Type:
Spring-Clamp
Housing Material:
Thermoplastic;Glass Fibre Reinforced
Auxiliary Contact:
Yes
Wire Cross Section:
0.50 to 1.50 mm²
Contact Configuration:
4NC
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-25 °C
Height:
184 mm
Weight:
340 g
Model Part Code:
SLK-F-UC-22-R1-A0-L0-0
