Balluff BUS Ultrasonic Sensor, M30, 200-2000mm Range, PNP NO/NC, M12 5-pin Connector, 9-30V DC, 8Hz, IP67

PART NO: BUS0039 / SKU: 1033513
Balluff BUS Ultrasonic Sensor, M30, 200-2000mm Range, PNP NO/NC, M12 5-pin Connector, 9-30V DC, 8Hz, IP67
$553.42
inc. GST
$503.11
ex. GST
Free shipping on orders over $100

Product Specification

Brand:
Balluff
Type:
Ultrasonic Sensor
Length:
94.5 mm
Accuracy:
±0.15 %
IP Rating:
IP67
Resolution:
≤0.180 mm
Application:
Object Detection
Output Type:
PNP
Model/Series:
BUS
Rated Current:
80 mA
Sensing Range:
200 to 2000 mm
Certifications:
cULus;CE;WEEE;UKCA
Connection Type:
M12
Output Function:
NO/NC
Housing Material:
Brass;PBT;TPU
Indicator Colour:
Yellow;Green
Input Signal Type:
Synchronization
Operating Voltage:
9 to 30 V DC
Display Technology:
LED
Switching Frequency:
8 Hz
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-25 °C
Weight:
148 g
Model Part Code:
BUS M30M1-PPX-20/130-S92K
Style:
M30
