Product Specification
Brand:
Balluff
Type:
Cubic Diffuse Sensor
Style:
Square
Width:
28.5 mm
Height:
80.5 mm
Length:
62 mm
Weight:
137.037 g
Frequency:
500 Hz
IP Rating:
IP67
Adjustable:
Yes
Light Type:
LED
Output Type:
PNP
Light Colour:
Red
Model/Series:
50K
Rated Current:
100 mA
Sensing Range:
200 to 2000 mm
Certifications:
CE;cULus;UKCA;WEEE
Connection Type:
4-Pin Male M12 x 1 Connector
Ecom Hide Price:
No
Light Spot Size:
60 x 60 mm
Model Part Code:
BOS 50K-PA-RH12-S4
Output Function:
NO/NC
Housing Material:
ABS;PC
Installation Type:
Screw Mount
Operating Voltage:
10 to 30 V DC
Sensing Surface Material:
Glass
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-10 °C
