Balluff BCC Field-Attachable Connector, M12 Female Straight, 5-Pin, Screw Terminals, 0.14-0.75mm², 6-8mm Cable
PART NO:
BCC06W9 /
SKU:
1042290
$12.38
inc. GST
$11.25
ex. GST
Product Specification
Brand:
Balluff
Type:
Field Attachable Connector
Material:
Brass (Contacts)
IP Rating:
IP67
Cable Size:
6 to 8 mm
Application:
Industrial
Coding Type:
A-coded
Model/Series:
BCC
Nut Material:
Die-cast zinc
Mounting Type:
Screw Mount
Rated Current:
4 A
Rated Voltage:
125 V AC/DC
Certifications:
CE;cULus;WEEE
Connection Type:
M12
Connector Gender:
Female
Number of Contacts:
5
Wire Cross Section:
0.14 to 0.75 mm²
Max Operating Temperature:
+85 °C
Min Operating Temperature:
-40 °C
Model Part Code:
BCC M435-0000-1A-000-51X575-000
