Advantech ADAM-5017H 8-Channel High-Speed Analog Input Module, 12-Bit, mV/V/mA

PART NO: ADAM-5017H-BE / SKU: 1032186
Advantech ADAM-5017H 8-Channel High-Speed Analog Input Module, 12-Bit, mV/V/mA
$506.00
inc. GST
$460.00
ex. GST
Free shipping on orders over $100

Product Specification

Brand:
Advantech
Type:
Analogue Input Module
Weight:
130 g
Wattage:
2.2 W
Accuracy:
±0.1 %
Humidity:
5 to 95 %
Resolution:
12 bit
Rated Current:
20 mA
Rated Voltage:
10 to 30 V DC
Sampling Rate:
100 KS/S
Certifications:
CE;FCC
Enclosure Type:
DIN Rail
Connection Type:
Screw Terminal
Input Impedance:
20 MΩ (Voltage);125 Ω (Current)
Input Signal Type:
mV;V;mA
Input Signal Range:
±250 mV;±500 mV;±1 V;±5 V;±10 V;0 to 500 mV;0 to 1 V;0 to 5 V;0 to 10 V;0 to 20 mA;4 to 20 mA
Number of Channels:
8
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-10 °C

Product Downloads

Datasheet Certificate 1 Certificate 2
