Product Specification
Brand:
Balluff
Type:
Inductive Sensor
Style:
M18
Width:
18 mm
Frequency:
430 Hz
IP Rating:
IP68
Output Type:
PNP
Model/Series:
BES
Rated Current:
200 mA
Sensing Range:
16 mm
Certifications:
CE;UKCA;cULus;WEEE
Connection Type:
3-Pin M12 x 1 Male Connector
Output Function:
NO
Housing Material:
Brass
Installation Type:
Non-Flush Mount
Operating Voltage:
10 to 30 V DC
Sensing Surface Material:
PBT
Max Operating Temperature:
+85 °C
Min Operating Temperature:
-40 °C
Height:
66 mm
Model Part Code:
BES M18MG-PSC16F-S04G
