Weidmuller TRS Series Plug-In Relay Module, 24V DC Coil, SPDT, Gold-Plated Contacts, 6A, TS 35 DIN Rail Mount

PART NO: 1123000000 / SKU: 1020312
Weidmuller TRS Series Plug-In Relay Module, 24V DC Coil, SPDT, Gold-Plated Contacts, 6A, TS 35 DIN Rail Mount
$26.84
inc. GST
$24.40
ex. GST
Free shipping on orders over $100

Discover the Weidmuller (1123000000) TRS Series Plug-In Relay Module, a versatile solution for your control applications.

  • Features a 24V DC coil for reliable operation.
  • Equipped with SPDT gold-plated contacts for excellent conductivity and durability, rated at 6A.
  • Designed for easy installation with TS 35 DIN Rail Mount.

Ensure robust and efficient performance with this advanced Weidmuller relay module.

Product Specification

Brand:
Weidmuller
Type:
Relay Module
Width:
6.4 mm
Colour:
Black
Length:
87.8 mm
Wattage:
280 mW
Function:
Protection
IP Rating:
IP20
Test Button:
No
Coil Voltage:
24 V DC
Model/Series:
TRS
Release Time:
≤16 ms
Mounting Type:
DIN Rail Mount
Rated Current:
6 A
Rated Voltage:
250 V AC
Terminal Type:
Screw
Certifications:
CE;cULus;DNV;UKCA;RoHS;UL
Conductor Type:
Rigid Copper Conductor;Flexible Copper Conductor
Operating Time:
≤6 ms
Connection Type:
Screw
Control Voltage:
24 V DC
Mechanical Life:
5 x 10^6 cycles
Contact Material:
AgNi
Status Indicator:
Yes
Number of Contacts:
1
Contact Configuration:
1CO
Protective Circuit Type:
Diode
Rated Switching Current:
6 A
Rated Switching Voltage:
250 V AC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-40 °C
Height:
89.6 mm
Weight:
33 g
Model Part Code:
TRS 24VDC 1CO AU
