Weidmuller TRS Multi-Function Timing Relay, DPDT, 24-230V UC, 8A, Screw Connection, TS35 DIN Rail Mount

PART NO: 2662880000 / SKU: 1035333
Weidmuller TRS Multi-Function Timing Relay, DPDT, 24-230V UC, 8A, Screw Connection, TS35 DIN Rail Mount
$61.29
inc. GST
$55.72
ex. GST
Free shipping on orders over $100

Discover the Weidmuller TRS Multi-Function Timing Relay (2662880000), a versatile solution for precise timing control.

  • Features a DPDT configuration for various applications.
  • Operates on 24-230V UC with an 8A capacity.
  • Designed for easy installation with screw connections and TS35 DIN Rail Mount.

Ensure reliable and efficient operation with this advanced Weidmuller timing relay.

Product Specification

Brand:
Weidmuller
Type:
Relay Module
Width:
12.8 mm
Colour:
Black
Length:
87.8 mm
Wattage:
540 mW @ 24 V DC;460 mW @ 230 V DC;565 mVA @ 24 V AC;1.0 VA @ 230 V AC
IP Rating:
IP20
Test Button:
No
Coil Voltage:
24 to 230 V AC/DC
Model/Series:
TRS
Release Time:
≤50 ms
Mounting Type:
DIN Rail Mount
Rated Current:
8 A
Rated Voltage:
250 V AC
Terminal Type:
Screw
Certifications:
CE;cULus;DNV;UKCA;RoHS;UL
Conductor Type:
Rigid Copper Conductor;Flexible Copper Conductor
Operating Time:
≤50 ms
Connection Type:
Screw
Control Voltage:
24 to 230 V AC/DC
Mechanical Life:
30 x 10^6 cycles
Contact Material:
AgNi
Status Indicator:
Yes
Number of Contacts:
2
Contact Configuration:
2CO
Protective Circuit Type:
Rectifier
Rated Switching Current:
8 A
Rated Switching Voltage:
250 V AC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-40 °C
Height:
89.6 mm
Weight:
62 g
Model Part Code:
TRS 24-230VUC 2CO ED2

Product Downloads

Datasheet
