Weidmuller TRS Interface Relay, SPDT, 16A, 24V AC/DC Coil, 250V AC Switching, Screw Terminals, TS 35 Mount

PART NO: 1479690000 / SKU: 1035939
Weidmuller TRS Interface Relay, SPDT, 16A, 24V AC/DC Coil, 250V AC Switching, Screw Terminals, TS 35 Mount
$43.20
inc. GST
$39.27
ex. GST
Free shipping on orders over $100

Discover the Weidmuller TRS Interface Relay (1479690000), a versatile solution for your electrical control needs.

  • Features SPDT contacts for single-pole, double-throw switching.
  • Equipped with a 24V AC/DC coil and capable of switching up to 250V AC at 16A.
  • Designed with screw terminals and suitable for TS 35 mount installations.

Enhance your system's reliability and control with this high-quality Weidmuller interface relay.

Product Specification

Brand:
Weidmuller
Type:
Relay Module
Width:
12.8 mm
Colour:
Black
Length:
87.8 mm
Wattage:
390 mVA;350 mW
IP Rating:
IP20
Test Button:
No
Coil Voltage:
24 V AC/DC
Model/Series:
TRS
Release Time:
≤16 ms
Mounting Type:
DIN Rail Mount
Rated Current:
16 A
Rated Voltage:
250 V AC
Terminal Type:
Screw
Certifications:
CE;cULus;DNV;UKCA;RoHS;UL
Conductor Type:
Rigid Copper Conductor;Flexible Copper Conductor
Operating Time:
≤5 ms
Connection Type:
Screw
Control Voltage:
24 V AC/DC
Mechanical Life:
30 x 10^6 cycles
Contact Material:
AgNi
Status Indicator:
Yes
Number of Contacts:
1
Contact Configuration:
1CO
Protective Circuit Type:
Rectifier
Rated Switching Current:
16 A
Rated Switching Voltage:
250 V AC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-40 °C
Height:
89.6 mm
Weight:
56 g
Model Part Code:
TRS 24VUC 1CO 16A
