Product Specification
Brand:
Weidmuller
Type:
Relay Module
Width:
12.80 mm
Colour:
Black
Length:
87.80 mm
IP Rating:
IP20
Test Button:
No
Coil Voltage:
24 V DC
Model/Series:
TRS
Release Time:
18 ms
Mounting Type:
TS35 Rail Mount
Rated Current:
8 A
Rated Voltage:
250 V AC
Terminal Type:
Screw
Certifications:
DNV;cULus;UKCA;RoHS:CE
Conductor Type:
Rigid Copper Conductor;Flexible Copper Conductor
Operating Time:
6 ms
Connection Type:
Screw
Control Voltage:
24 V DC
Mechanical Life:
30 x 10^6 Cycles
Contact Material:
AgNi
Status Indicator:
Yes
Number of Contacts:
2
Contact Configuration:
2CO
Protective Circuit Type:
Diode
Rated Switching Current:
8 A
Rated Switching Voltage:
250 V AC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-40 °C
Height:
89.60 mm
Weight:
56 g
Model Part Code:
TRS 24VDC 2CO
