Product Specification
Brand:
Weidmuller
Type:
Power Supply
Width:
35 mm
Material:
Metal
Frequency:
45 to 65 Hz
IP Rating:
IP20
Input Type:
Single Phase
Model/Series:
Pro Top
Output Power:
120 W
Internal Fuse:
Yes
Terminal Type:
Push In
Certifications:
CE;cULus;cURus;cULus Ex;TUV;RoHS;REACH
Output Current:
5 A
Output Voltage:
24 V DC
Input Voltage AC:
85 to 277 V AC
Input Voltage DC:
48 to 410 V DC
Surge Protection:
Yes
Number of Outputs:
5
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-25 °C
Number of Input Terminals:
3
Depth:
125 mm
Height:
130 mm
Weight:
850 g
Model Part Code:
PRO TOP1 120W 24V 5A
