Product Specification
Brand:
Weidmuller
Type:
Feed Through Terminal Block
Width:
6.1 mm
Colour:
Dark Beige
Function:
Single Level Feed Through
Material:
Wemid
Blade Size:
0.6 x 3.5 mm
Cable Size:
26 to 12 AWG
Model/Series:
A3C
Mounting Type:
TS35 Rail Mount
Rated Current:
32 A
Rated Voltage:
800 V
Certifications:
CCCEX;CE;CSA;cURus;cURus Ex;DNV;IEC Ex;KEMA;KEUR;KOSHA Ex;UKCA;RoHS
Connection Type:
Push In
Number of Levels:
1
Stripping Length:
12 mm
Max Clamping Range:
6 mm²
Min Clamping Range:
0.14 mm²
Wire Cross Section:
4 mm²
Connection Direction:
Right
Number of Connections:
3
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
39.5 mm
Height:
74 mm
Weight:
12.204 g
Model Part Code:
A3C 4
