IDEC RH2B Compact Power Relay, DPDT, 10A, 48V DC Coil, Plug-In

PART NO: RH2B-UDC48V / SKU: 1002527
IDEC RH2B Compact Power Relay, DPDT, 10A, 48V DC Coil, Plug-In
$28.93
inc. GST
$26.30
ex. GST
Free shipping on orders over $100

Discover the versatile IDEC RH2B Compact Power Relay (RH2B-UDC48V), engineered for reliable performance in various applications.

  • Compact DPDT design for efficient switching.
  • 10A current rating to handle demanding loads.
  • Features a 48V DC coil and plug-in terminals for easy installation.

This IDEC relay is an ideal choice for your power control needs, offering durability and ease of use.

Product Specification

Brand:
Idec
Type:
Relay
Width:
21 mm
Colour:
Transparent
Length:
27.5 mm
Test Button:
No
Coil Voltage:
48 V DC
Model/Series:
RH
Release Time:
25 ms
Mounting Type:
Socket Mount
Rated Current:
10 A
Rated Voltage:
48 V DC
Terminal Type:
Blade
Certifications:
CSA;ULus;TUV;CE;cURus
Operating Time:
20 ms
Connection Type:
Blade Terminal
Control Voltage:
48 V DC
Mechanical Life:
500M Cycles
Contact Material:
AgCdO
Status Indicator:
No
Country of Origin:
Japan
Number of Contacts:
2
Contact Configuration:
2CO
Rated Switching Current:
10 A
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-30 °C
Height:
42 mm
Weight:
37 g

Product Downloads

Datasheet
