IDEC HW1B Pushbutton Switch, 22mm, Momentary, 1NO 1NC, Blue, Flush, 10A, Screw Terminals, Plastic Bezel

PART NO: HW1B-M1F11-S / SKU: 1002224
IDEC HW1B Pushbutton Switch, 22mm, Momentary, 1NO 1NC, Blue, Flush, 10A, Screw Terminals, Plastic Bezel
$58.30
inc. GST
$53.00
ex. GST
Free shipping on orders over $100

Discover the versatile IDEC HW1B Pushbutton Switch, a reliable component from Idec (HW1B-M1F11-S).

  • Features a 22mm, momentary action with 1 normally open (NO) and 1 normally closed (NC) contact.
  • Designed with a flush blue button and a durable plastic bezel for a sleek appearance.
  • Rated for 10A and equipped with secure screw terminals for easy installation.

Enhance your control systems with the quality and performance of this IDEC pushbutton switch.

Product Specification

Brand:
Idec
LED:
No
Type:
Push Button
Width:
62.4 mm
Colour:
Blue
Length:
29.4 mm
Material:
Plastic
IP Rating:
IP20
Bezel Type:
Round
Illuminated:
No
Model/Series:
HW
Mounting Type:
Panel Mount
Rated Current:
10 A
Rated Voltage:
600 V
Certifications:
UL E68961;CSA;CE;CCC;TUV
Operation Type:
Momentary
Operator Shape:
Round
Operator Style:
Flush
Connection Type:
Screw
Mounting Hole Size:
22 mm
Contact Configuration:
1NO/1NC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-25 °C
Height:
41.4 mm

Product Downloads

Datasheet
