Bernstein AG SLK Guard Locking Safety Switch with Separate Actuator, 2NC/2NO, 24V DC, Plastic Body, IP67

PART NO: 6118119163 / SKU: 1037631
Bernstein AG SLK Guard Locking Safety Switch with Separate Actuator, 2NC/2NO, 24V DC, Plastic Body, IP67
$467.50
inc. GST
$425.00
ex. GST
Free shipping on orders over $100

Checkout the Bernstein AG SLK Guard Locking Safety Switch (6118119163), a reliable solution for enhanced safety in industrial applications.

  • Features a separate actuator for secure guard locking.
  • Equipped with 2NC/2NO contacts for versatile wiring options.
  • Operates on 24V DC and boasts an IP67 rating for robust protection in demanding environments.

Ensure superior safety and operational integrity with this advanced Bernstein AG safety switch.

Product Specification

Brand:
Bernstein
Type:
Guard Locking Safety Switch
Class:
Class II
Width:
45 mm
Length:
42.5 mm
IP Rating:
IP67
Tolerance:
±15 %
Entry Type:
3 x M20
Handle Type:
Rotary
Title Plate:
No
Model/Series:
SLK
Actuator Type:
Spring
Rated Current:
5 A
Rated Voltage:
24 V DC
Certifications:
VDE 0660 T100;DIN EN 60947-1;IEC 60947-1;VDE 0660 T200;DIN EN 60947-5-1;IEC 60947-5-1;DIN EN ISO 13849-1;GS-ET-19;DGUV;cCSAus;CCC
Operation Type:
Spring Force
Connection Type:
M20
Housing Material:
Thermoplastic;Glass Fibre Reinforced
Wire Cross Section:
0.5 to 1.5 mm²
Contact Configuration:
2NO/2NC
Number of Connections:
4
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-25 °C
Height:
170 mm
Weight:
370 g

Product Downloads

Datasheet
