Bernstein AG SCR Safety Relay, PNP NO Output, 3NO, 24V DC, Screw Terminals, IO-Link, NFC, DIN Rail Mount

PART NO: 6075113147 / SKU: 1038690
Bernstein AG SCR Safety Relay, PNP NO Output, 3NO, 24V DC, Screw Terminals, IO-Link, NFC, DIN Rail Mount
$627.00
inc. GST
$570.00
ex. GST
Free shipping on orders over $100

Explore the Bernstein 6075113147 SCR Safety Relay, a high-performance component designed for robust safety applications.

  • Features a PNP NO output with 3NO contacts for reliable signal transmission.
  • Operates on 24V DC and includes convenient screw terminals for secure wiring.
  • Equipped with IO-Link and NFC for advanced communication and configuration, and designed for DIN Rail Mount installation.

Ensure enhanced safety and seamless integration with this advanced Bernstein AG safety relay.

Product Specification

Brand:
Bernstein
Type:
Safety Relay
Width:
23 mm
Colour:
Black (Enclosure);Yellow (Front Plate)
Length:
121 mm
Wattage:
2000 VA
Function:
Protection
Material:
PA-GF (Enclosure);PBT (Front Plate)
IP Rating:
IP20
Coil Voltage:
24 V DC
Model/Series:
SCR DI
Release Time:
Mounting Type:
DIN Rail Mount
Rated Current:
8 A
Rated Voltage:
250 V AC
Certifications:
TUV
Operating Time:
Connection Type:
Screw
Control Voltage:
24 V DC
Contact Material:
AgCuNi +0.2 μm Au
Status Indicator:
Yes
Number of Contacts:
3
Contact Configuration:
3NO
Rated Switching Current:
8 A
Rated Switching Voltage:
250 V AC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
0 °C
Height:
108 mm

Product Downloads

Datasheet
