Product Specification
Brand:
Bernstein
Type:
Limit Switch
Class:
Class II
Width:
30.3 mm
IP Rating:
IP66;IP67
Entry Type:
M20 x 1.5
Model/Series:
IN65
Actuator Type:
Plunger
Rated Current:
5 A
Rated Voltage:
240 V AC;24 V DC
Certifications:
VDE 0660 T211;DIN EN 60947-5-4;IEC 60947-5-4;DIN EN ISO 13849-1;DIN EN ISO 13849-2
Component Type:
Body with Actuator
Latch Function:
Latching
Operation Type:
Snap Action
Housing Material:
Thermoplastic;Glass Fibre Reinforced
Contact Configuration:
1NC/1NO
Max Operating Temperature:
+75 °C
Min Operating Temperature:
-30 °C
Depth:
74 mm
