Advantech ICR-3232 Industrial IoT 4G LTE Router & Gateway, LTE Cat.4, 2x Ethernet 10/100, 1x RS232, 1x RS485

PART NO: ICR-3232 / SKU: 1032700
Advantech ICR-3232 Industrial IoT 4G LTE Router & Gateway, LTE Cat.4, 2x Ethernet 10/100, 1x RS232, 1x RS485
$603.90
inc. GST
$549.00
ex. GST
Free shipping on orders over $100

Discover the Advantech ICR-3232, a high-performance industrial IoT 4G LTE router and gateway designed for robust connectivity.


  • Features LTE Cat.4 for reliable high-speed wireless communication.
  • Equipped with 2x Ethernet 10/100 ports for versatile network integration.
  • Includes 1x RS232 and 1x RS485 serial ports for diverse industrial applications.

Optimize your industrial IoT deployments with the dependable and versatile Advantech ICR-3232.

Product Specification

Brand:
Advantech
Type:
Industrial IoT Gateway
Width:
129 mm
Wattage:
2.5 W (Idle);4 W (Average);11 W (Maximum)
IP Rating:
IP30
Memory Size:
512 MB
Input/Output:
1 x Digital Input;1 x Digital Input
Model/Series:
ICR
Mounting Type:
DIN Rail Mount;Wall Mount
Rated Voltage:
9 to 36 V DC
Certifications:
CE;BS EN;EN;CISPR;EN IEC
Number of Ethernet Ports:
2
Max Operating Temperature:
+75 °C
Min Operating Temperature:
-40 °C
Depth:
94 mm
Height:
31 mm
Weight:
457 kg

Product Downloads

Datasheet
