Weidmuller TRS Interface Relay, DPDT, 8A, 48V AC/DC Coil, 250V AC Switching, Screw, TS 35 DIN Rail Mount

PART NO: 1123510000 / SKU: 1019165
Weidmuller TRS Interface Relay, DPDT, 8A, 48V AC/DC Coil, 250V AC Switching, Screw, TS 35 DIN Rail Mount
$38.31
inc. GST
$34.83
ex. GST
Free shipping on orders over $100

Discover the high-performance Weidmuller TRS Interface Relay (1123510000), engineered for reliable signal interfacing in industrial applications.

  • Features a DPDT configuration and 8A switching capacity for versatile control.
  • Equipped with a 48V AC/DC coil and capable of switching up to 250V AC.
  • Designed for easy installation with screw connections and TS 35 DIN Rail Mount compatibility.

Ensure robust and efficient operations with this essential Weidmuller interface relay.

Product Specification

Brand:
Weidmuller
Type:
Relay Module
Width:
12.8 mm
Colour:
Black
Length:
87.8 mm
Wattage:
340 mW;0.4 VA
IP Rating:
IP20
Test Button:
No
Coil Voltage:
48 V AC/DC
Model/Series:
TRS
Release Time:
≤7 ms
Mounting Type:
DIN Rail Mount
Rated Current:
8 A
Rated Voltage:
250 V AC
Terminal Type:
Screw
Certifications:
CE;cULus;DNV;UKCA;RoHS;UL
Conductor Type:
Rigid Copper Conductor;Flexible Copper Conductor
Operating Time:
≤11 ms
Connection Type:
Screw
Control Voltage:
48 V AC/DC
Mechanical Life:
30 x 10^6 cycles
Contact Material:
AgNi
Status Indicator:
Yes
Number of Contacts:
2
Contact Configuration:
2CO
Protective Circuit Type:
Rectifier
Rated Switching Current:
8 A
Rated Switching Voltage:
250 V AC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-40 °C
Height:
89.6 mm
Weight:
57 g
Model Part Code:
TRS 48VUC 2CO
