Weidmuller TRS Compact Relay, SPDT, 6A, 120V AC/DC Coil, 250V AC Switching, Screw Terminals, Status LED

PART NO: 1122810000 / SKU: 1019159
Weidmuller TRS Compact Relay, SPDT, 6A, 120V AC/DC Coil, 250V AC Switching, Screw Terminals, Status LED
$38.31
inc. GST
$34.83
ex. GST
Free shipping on orders over $100

Explore the Weidmuller TRS Compact Relay (1122810000).

  • Features SPDT, 6A, 120V AC/DC Coil, and 250V AC Switching.
  • Equipped with convenient screw terminals.
  • Includes a status LED for easy monitoring.

Ensure reliable and compact relay performance with this advanced Weidmuller product.

Product Specification

Brand:
Weidmuller
Type:
Relay Module
Width:
6.4 mm
Colour:
Black
Length:
87.8 mm
Wattage:
0.48 VA;420 mW
IP Rating:
IP20
Test Button:
No
Coil Voltage:
120 V AC/DC
Model/Series:
TRS
Release Time:
≤40 ms
Mounting Type:
DIN Rail Mount
Rated Current:
6 A
Rated Voltage:
250 V AC
Terminal Type:
Screw
Certifications:
CE;cULus;DNV;UKCA;RoHS;UL
Conductor Type:
Rigid Copper Conductor;Flexible Copper Conductor
Operating Time:
≤11 ms
Connection Type:
Screw
Control Voltage:
120 V AC/DC
Mechanical Life:
5 x 10^6 cycles
Contact Material:
AgNi
Status Indicator:
Yes
Number of Contacts:
1
Contact Configuration:
1CO
Protective Circuit Type:
Rectifier
Rated Switching Current:
6 A
Rated Switching Voltage:
250 V AC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-40 °C
Height:
89.6 mm
Weight:
34 g
Model Part Code:
TRS 120VUC 1CO
