Weidmuller TOZ Solid-State Relay, 1 NO Contact, 24V DC Control, 3-33V DC Switching, 2A, TS 35 DIN Rail Mount

PART NO: 1127290000 / SKU: 1025556
Weidmuller TOZ Solid-State Relay, 1 NO Contact, 24V DC Control, 3-33V DC Switching, 2A, TS 35 DIN Rail Mount
$49.82
inc. GST
$45.29
ex. GST
Free shipping on orders over $100

Discover the Weidmuller TOZ Solid-State Relay (1127290000), a highly efficient solution for industrial control applications.

  • Features a 1 NO contact configuration for straightforward integration.
  • Operates with 24V DC control and 3-33V DC switching for flexible power compatibility.
  • Designed for TS 35 DIN Rail Mount, ensuring secure and easy installation.

Enhance your system's performance and reliability with this advanced Weidmuller solid-state relay.

Product Specification

Brand:
Weidmuller
Type:
Solid State Relay
Width:
6.4 mm
Colour:
Black
Length:
87.8 mm
Wattage:
280 mW
Function:
Protection
Frequency:
300 Hz
IP Rating:
IP20
Test Button:
No
Coil Voltage:
24 V DC
Model/Series:
TOZ
Release Time:
Mounting Type:
DIN Rail Mount
Rated Current:
2 A
Rated Voltage:
3 to 33 V DC
Terminal Type:
Tension Clamp
Certifications:
CE;cULus;DNV;UKCA;RoHS;UL
Conductor Type:
Rigid Copper Conductor;Flexible Copper Conductor
Operating Time:
≤0.1 ms
Connection Type:
Tension Clamp
Control Voltage:
24 V DC
Status Indicator:
Yes
Number of Contacts:
1
Contact Configuration:
1NO
Protective Circuit Type:
Diode
Rated Switching Current:
2 A
Rated Switching Voltage:
3 to 33 V DC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-20 °C
Height:
90.5 mm
Weight:
26 g
Model Part Code:
TOZ 24VDC 24VDC2A
