Weidmuller RS Relay Module, DPDT, 115/230V UC, 4A, Screw Connection, LED Indicator, Orange, TS 32/35 Mount

PART NO: 1122761001 / SKU: 1012137
Weidmuller RS Relay Module, DPDT, 115/230V UC, 4A, Screw Connection, LED Indicator, Orange, TS 32/35 Mount
$235.64
inc. GST
$214.22
ex. GST
Free shipping on orders over $100

Explore the high-performance Weidmuller RS Relay Module (1122761001), designed for reliable control in various applications.

  • Features a DPDT configuration and operates on 115/230V UC.
  • Equipped with a 4A current rating and convenient screw connections for easy installation.
  • Includes an LED indicator for clear status visualization and is designed for TS 32/35 mount.

Ensure efficient and secure control with this robust and versatile relay module from Weidmuller.

Product Specification

Brand:
Weidmuller
Type:
Relay Module
Width:
25 mm
Colour:
Orange
Length:
63.5 mm
Wattage:
1 W;1 VA
IP Rating:
IP20
Test Button:
No
Coil Voltage:
115 to 230 V AC/DC
Model/Series:
RS
Release Time:
≤10 ms
Mounting Type:
DIN Rail Mount
Rated Current:
4 A
Rated Voltage:
250 V AC
Terminal Type:
Screw
Certifications:
CE;RoHS
Operating Time:
Connection Type:
Screw
Control Voltage:
115 to 230 V AC/DC
Mechanical Life:
30 x 10^6 cycles
Contact Material:
AgNi
Status Indicator:
Yes
Number of Contacts:
2
Contact Configuration:
2CO
Protective Circuit Type:
Rectifier
Rated Switching Current:
4 A
Rated Switching Voltage:
250 V AC
Max Operating Temperature:
+40 °C
Min Operating Temperature:
-25 °C
Height:
70 mm
Weight:
46.88 g
Model Part Code:
RS 32 115-230VUC LD 2U

Product Downloads

Datasheet
