Product Specification
Brand:
Weidmuller
Type:
Supply Terminal
Width:
8.1 mm
Colour:
Dark Beige
Function:
Single Level Feed Through
Material:
Wemid
Model/Series:
AAP13
Mounting Type:
TS35 Rail Mount
Rated Current:
41 A
Rated Voltage:
250 V
Certifications:
CCCEX;CE;CSA;cURus;DNV;IEC Ex;KOSHA Ex;UKCA;RoHS
Connection Type:
Push In
Number of Levels:
1
Wire Cross Section:
6 mm²
Connection Direction:
Top
Number of Potentials:
2
Number of Connections:
2
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
47 mm
Height:
96 mm
Weight:
22.31 g
Model Part Code:
AAP13 6 LO-LO
