Raytec SPX Hazardous Area LED Batten Light, 110 to 254V AC, 49W, 4000K, Zone 1/21

PART NO: SPX-WL168-4K / SKU: 1035774
Raytec SPX Hazardous Area LED Batten Light, 110 to 254V AC, 49W, 4000K, Zone 1/21

Contact Us For Pricing

Pricing for this product is not available online. Please contact us for more details and purchasing options.

Contact Us
Free shipping on orders over $100
$1,749.00
inc. GST
$1,590.00
ex. GST
Free shipping on orders over $100

Discover the Raytec SPX-WL168-4K Hazardous Area LED Batten Light, engineered for optimal performance in challenging environments.


  • Designed for hazardous areas: Zone 1/21 certified.
  • Wide voltage input: Operates on 110 to 254V AC.
  • Efficient illumination: Provides 4000K light at 49W.

Ensure reliable and safe lighting solutions with this advanced Raytec SPX batten light.

Product Specification

Brand:
Raytec
Type:
Batten Light
Width:
174 mm
Length:
1251 mm
Wattage:
49 W
IK Rating:
IK10
IP Rating:
IP66;IP67
Beam Angle:
120 ° x 120 °
Model/Series:
SPX
Power Supply:
Modular Driver
Lens Material:
Polycarbonate
Mounting Type:
Wall Mount;Ceiling Mount
Rated Voltage:
110 to 254 V AC
Certifications:
CML14ATEX3119;IECEx CML15.0001;CML21UKEX3105
IECEx Gas Zone:
Zone 1
Connection Type:
M20 Entry
Ecom Hide Price:
No
IECEx Dust Zone:
Zone 21
Emergency Backup:
No
Housing Material:
Aluminium
Country of Origin:
United Kingdom
Colour Temperature:
4000 K
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-40 °C
Height:
118 mm
Weight:
9 kg

Warranty Information

5 Years

Product Downloads

Datasheet
