Microsonic mic+25 Ultrasonic Sensor, M30, 30-350mm Range, 1x PNP NO/NC, 9-30V DC, LED Display, IP67

PART NO: mic+25/D/TC / SKU: 1006416
Microsonic mic+25 Ultrasonic Sensor, M30, 30-350mm Range, 1x PNP NO/NC, 9-30V DC, LED Display, IP67
$419.10
inc. GST
$381.00
ex. GST
Free shipping on orders over $100

Discover the Microsonic mic+25/D/TC Ultrasonic Sensor, a high-performance solution for precise distance measurement.

  • Features a 30-350mm range for versatile applications.
  • Equipped with 1x PNP NO/NC output and operates on 9-30V DC.
  • Includes an LED display and boasts an IP67 rating for robust protection.

Enhance your automation systems with the reliability and accuracy of this Microsonic ultrasonic sensor.

Product Specification

Brand:
Microsonic
Type:
Ultrasonic Sensor
Style:
M30
Length:
84 mm
Accuracy:
±1 %
Function:
Proximity
IP Rating:
IP67
Resolution:
0.025 mm
Output Type:
PNP
Model/Series:
mic+
Rated Current:
80 mA
Sensing Range:
30 to 350 mm
Certifications:
UL
Connection Type:
M12
Output Function:
NO/NC
Housing Material:
Brass Sleeve;Plastic Parts;PBT;TPU
Input Signal Type:
Synchronization
Operating Voltage:
9 to 30 V DC
Display Technology:
LED
Switching Frequency:
320 kHz
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-25 °C
Weight:
150 g

Product Downloads

Datasheet
