Microsonic esf Ultrasonic Label and Splice Sensor, 2x Push-Pull/PNP Outputs, 20-30V DC, IO-Link, IP65

PART NO: esf-1/7/CDF/A / SKU: 1041465
Microsonic esf Ultrasonic Label and Splice Sensor, 2x Push-Pull/PNP Outputs, 20-30V DC, IO-Link, IP65
$1,167.10
inc. GST
$1,061.00
ex. GST
Free shipping on orders over $100

Discover the Microsonic esf-1/7/CDF/A Ultrasonic Label and Splice Sensor, engineered for precision and reliability in diverse industrial applications.

  • Utilizes advanced ultrasonic technology for accurate label and splice detection.
  • Features 2x Push-Pull/PNP Outputs for flexible integration into existing systems.
  • Operates on 20-30V DC and includes IO-Link connectivity, all within an IP65 rated enclosure for robust performance in challenging environments.

Enhance your operational efficiency and accuracy with this cutting-edge Microsonic ultrasonic sensor.

Product Specification

Brand:
Microsonic
Type:
Splice Sensor
Style:
Fork-like
Width:
16 mm
Length:
100 mm
Function:
Label and Splice
IP Rating:
IP65
Output Type:
Push-Pull PNP
Model/Series:
ESF
Rated Current:
50 mA
Certifications:
UL
Connection Type:
M12
Output Function:
NO/NC
Housing Material:
Aluminium
Indicator Colour:
Green;Yellow;Red
Input Signal Type:
Synchronization
Operating Voltage:
20 to 30 V DC
Switching Frequency:
500 kHz
Max Operating Temperature:
+60 °C
Min Operating Temperature:
+5 °C
Height:
39 mm
Weight:
80 g
