IDEC RH1B Compact Power Relay, SPDT, 10A, 24V DC Coil, Plug-In with LED and Diode

PART NO: RH1B-ULD-DC24V / SKU: 1002515
IDEC RH1B Compact Power Relay, SPDT, 10A, 24V DC Coil, Plug-In with LED and Diode
$37.62
inc. GST
$34.20
ex. GST
Free shipping on orders over $100

Explore the IDEC RH1B-ULD-DC24V Compact Power Relay, a robust solution for reliable power applications.

  • SPDT configuration for versatile switching.
  • 10A capacity to handle various electrical loads.
  • 24V DC Coil with LED and Diode for easy monitoring and protection.

Ensure superior performance and operational integrity with this advanced Idec compact power relay.

Product Specification

Brand:
Idec
Type:
Relay
Width:
14 mm
Colour:
Transparent
Length:
27.5 mm
Function:
Monostable
Test Button:
No
Coil Voltage:
24 V DC
Model/Series:
RH
Release Time:
20 ms
Mounting Type:
Socket Mount
Rated Current:
10 A
Rated Voltage:
24 V DC
Terminal Type:
Blade
Certifications:
CSA;ULus;TUV;CE;cURus
Operating Time:
20 ms
Connection Type:
Blade Terminal
Control Voltage:
24 V DC
Mechanical Life:
500M Cycles
Contact Material:
AgCdO
Status Indicator:
Yes
Country of Origin:
Japan
Number of Contacts:
1
Contact Configuration:
1CO
Protective Circuit Type:
Diode
Rated Switching Current:
10 A
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-30 °C
Height:
42 mm
Weight:
24 g

Product Downloads

Datasheet
