Danfoss IC2 Compact Variable Speed Drive, 0.37kW, 1.2A, 0.5hp, 380-480V AC, Three-Phase, IP20

PART NO: 132L6128 / SKU: 1041959
Danfoss IC2 Compact Variable Speed Drive, 0.37kW, 1.2A, 0.5hp, 380-480V AC, Three-Phase, IP20
$344.58
inc. GST
$313.25
ex. GST
Free shipping on orders over $100
  • Compact design with a small footprint for tight spaces, supports side-by-side mounting to minimize cabinet size.
  • Equipped with application setup wizards, spring-type I/O terminals, and MyDrive® Suite digital tools.
  • Compatible with all typical motor technologies, including induction motors (IM), permanent magnet synchronous motors (SPM), and interior permanent magnet (IPM) motors.
  • Includes coated PCBs as standard for harsh environments, a removable cooling fan and built-in RFI filter.
  • Features a built-in control panel with a 6-digit LED display, status indicators, and a frequency-setting potentiometer.

Product Specification

Brand:
Danfoss
Type:
General Purpose Micro Drive
Brake:
No
Depth:
158 mm
Phase:
Three Phase
Width:
70 mm
Height:
150 mm
Weight:
1.38 kg
Wattage:
0.37 kW
Frequency:
50 Hz;60 Hz
IP Rating:
IP20
Frame Size:
MA01a
Application:
General Purpose
Model/Series:
IC2
Rated Current:
1.2 A
Supply Voltage:
380 to 480 V AC
Ecom Hide Price:
No
Model Part Code:
IC2-30FA3N04-01A2E20F2+ACXX

Product Downloads

Datasheet
