Product Specification
Brand:
Bernstein
Type:
Foot Switch
Width:
250 mm
Length:
156 mm
Material:
Cast Aluminium;Thermoplastic
IP Rating:
IP65
Safety Type:
Safety Lock with Manual Release
Manual Reset:
No
Model/Series:
F1
Actuator Type:
Foot Lever
Rated Current:
3 A
Rated Voltage:
240 V AC
Certifications:
VDE 0660 T100;DIN EN 60947-1;IEC 60947-1;VDE 0660 T200;DIN EN 60947-5-1;IEC 60947-5-1
Operation Type:
Slow Action
Pedal 1 Stages:
Single
Connection Type:
Screw
Pedal 1 Contact:
1NO/1NC
Number of Pedals:
1
Protective Cover:
Yes
Contact Configuration:
1NO/1NC
Number of Connections:
4
Max Operating Temperature:
+80 °C
Min Operating Temperature:
-30 °C
Height:
145 mm
Weight:
1.50 kg
Warranty Information
1 Year
