Bernstein D Series Metal Bodied Limit Switch, Push Bolt Actuator, 1NC/1NO, 10A, 240V, 2x M20 Cable Entry, IP65

PART NO: 6041103002 / SKU: 1017839

$146.30
inc. GST
$133.00
ex. GST
Free shipping on orders over $100

Discover the Bernstein D Series Metal Bodied Limit Switch from Bernstein (6041103002), a robust solution designed for demanding industrial applications.

  • Features a durable metal body and a push bolt actuator for reliable performance.
  • Equipped with 1NC/1NO contacts and a 10A, 240V rating for versatile electrical integration.
  • Offers IP65 protection and dual M20 cable entries for secure and protected installation.

Ensure reliable and safe operation in your systems with this high-quality Bernstein limit switch.

Product Specification

Brand:
Bernstein
Type:
Limit Switch
Class:
Class I
Width:
44 mm
Length:
82 mm
IP Rating:
IP65
Tolerance:
±10 %
Entry Type:
M20
Model/Series:
D
Actuator Type:
Push Bolt
Rated Current:
10 A
Rated Voltage:
240 V
Certifications:
DIN EN 60947-5-1;cCSAus
Component Type:
Actuator
Operation Type:
Snap
Housing Material:
Die Cast Aluminium
Contact Configuration:
1NC/1NO
Max Operating Temperature:
+80 °C
Min Operating Temperature:
-30 °C
Depth:
79 mm
Weight:
270 g
