Bernstein AG F1-SU2ZP Foot Switch, Single Pedal, 2NO/2NC, 10A, 240V, Aluminum, IP65, M20 Entry

PART NO: 6061400572 / SKU: 1039628
Bernstein AG F1-SU2ZP Foot Switch, Single Pedal, 2NO/2NC, 10A, 240V, Aluminum, IP65, M20 Entry
$283.80
inc. GST
$258.00
ex. GST
Free shipping on orders over $100

Introducing the Bernstein AG F1-SU2ZP Foot Switch (6061400572), a durable and reliable solution for industrial control applications.

  • Features a single pedal design for straightforward operation.
  • Equipped with 2NO/2NC contacts and rated for 10A, 240V, ensuring robust electrical performance.
  • Constructed from aluminum with an IP65 rating and M20 entry, providing excellent protection in demanding environments.

This Bernstein AG foot switch delivers dependable performance and control for a wide range of machinery.

Product Specification

Brand:
Bernstein
Type:
Foot Switch
Width:
220 mm
Length:
70 mm
Material:
Die Cast Aluminium
Assembled:
Yes
IP Rating:
IP65
Entry Type:
M20
Safety Type:
Hinged Pedal Protection
Manual Reset:
No
Model/Series:
F1
Actuator Type:
Foot Lever
Rated Current:
10 A
Rated Voltage:
240 V
Certifications:
DIN EN ISO 13849-1;VDE 0660 T100;DIN EN 60947-1;IEC 60947-1;VDE 0660 T200;DIN EN 60947-5-1;IEC 60947-5-1;cCSAus;CCC
Operation Type:
Snap;Slow
Pedal 1 Stages:
Single
Pressure Point:
No
Connection Type:
Screw
Pedal 1 Contact:
2NO/2NC
Number of Pedals:
1
Protective Cover:
Yes
Contact Configuration:
2NC/2NO
Number of Connections:
8
Max Operating Temperature:
+80 °C
Min Operating Temperature:
-30 °C
Height:
60 mm
Weight:
700 g

Product Downloads

Datasheet
