Bernstein AG D Series Metal Body Limit Switch, 2NC/2NO, Metal Lever Actuator, 2x M20 Cable Entry, IP65

PART NO: 6142200765 / SKU: 1027258
Bernstein AG D Series Metal Body Limit Switch, 2NC/2NO, Metal Lever Actuator, 2x M20 Cable Entry, IP65
$541.20
inc. GST
$492.00
ex. GST
Free shipping on orders over $100

Discover the robust Bernstein AG D Series Metal Body Limit Switch (6142200765), engineered for reliable performance in demanding environments.

  • Features 2NC/2NO contacts for flexible control options.
  • Equipped with a durable metal lever actuator for consistent operation.
  • Includes 2x M20 cable entries and an IP65 rating for excellent protection against dust and water.

Ensure reliable and safe operation with this high-quality Bernstein AG limit switch.

Product Specification

Brand:
Bernstein
Type:
Limit Switch
Class:
Class I
Width:
45.5 mm
Length:
82 mm
IP Rating:
IP65
Entry Type:
M20
Model/Series:
D
Actuator Type:
Lever
Rated Current:
10 A
Rated Voltage:
240 V
Certifications:
DIN EN 60947-5-1;cCSAus;CCC
Component Type:
Actuator
Operation Type:
Snap
Housing Material:
Die Cast Aluminium
Contact Configuration:
2NC/2NO
Max Operating Temperature:
+80 °C
Min Operating Temperature:
-40 °C
Depth:
154 mm
Weight:
400 g

Product Downloads

Datasheet
